Through hole (DIP type) double digits 0.36 inch character height display

Feature and application for Through hole (DIP type) double digits 0.36 inch character height display

Dimension: 15mm x 14mm x 7.0mm
Surface color: Gray&black
Forward current: 10mA
RoHS compliant
Application:
Industry computer
Instruments panels
Counter equipment
Power meter
# PDF Part No Emitted Color λd(nm) λp(nm) Iv (mcd) Min. (Per Segment) Iv (mcd) Typ. (Per Segment) VF (Volt) @IF (mA) Configuration Surface Color Length (mm) Width (mm) Height (mm)
1 VP 452AG Green 573 575 3.55 5.6 2.0 10 C.A. Gray 15 14 7
2 VP 452CG Green 573 575 3.55 5.6 2.0 10 C.C. Gray 15 14 7
3 VP 472AG Red 624 632 5.6 9.0 2.0 10 C.A. Gray 15 14 7
4 VP 472CG Red 624 632 5.6 9.0 2.0 10 C.C. Gray 15 14 7
