Through hole (DIP type) single digit 0.80 inch character height display

Feature and application for Through hole (DIP type) single digit 0.80 inch character height display

Dimension:
25mm x18.6mm x10.6mm VP Kx1xG series
29mm x 20mm x 10.1mm VP Lx1xG series
27.7mm x 19.9mm x8.4mm VP Lx1xG-6 series
Surface color: Gray
Forward current: 10mA
RoHS compliant
Application:
Industry computer
Instruments panels
Counter equipment
Power meter
# PDF Part No Emitted Color λd(nm) Iv (mcd) Typ. (Per Segment) VF (Volt) @IF (mA) Configuration Surface Color
1 VP K51AG Green 573 7.8 2.0 10 C.A. Gray
2 VP K51CG Green 573 7.8 2.0 10 C.C. Gray
3 VP K71AG Red 624 14 2.0 10 C.A. Gray
4 VP K71CG Red 624 14 2.0 10 C.C. Gray
5 VP L51AG Green 573 7.8 2.0 10 C.A. Gray
6 VP L51CG Green 573 7.8 2.0 10 C.C. Gray
7 VP L71AG Red 624 14 2.0 10 C.A. Gray
8 VP L71CG Red 624 14 2.0 10 C.C. Gray
9 VP L51AG-6 Green 573 7.8 2.0 10 C.A. Gray
10 VP L51CG-6 Green 573 7.8 2.0 10 C.C. Gray
11 VP L71AG-6 Red 624 14 2.0 10 C.A. Gray
12 VP L71CG-6 Red 624 14 2.0 10 C.C. Gray
