SMD double digits 0.56 inch character height display

Feature and application for SMD double digits 0.56 inch character height display

Dimension: 25mm x 19mm x 3.8mm
configuration: common cathode
Surface color: Gray
Forward current: 10mA
RoHS compliant

0.56'' Character Height

#	Part No	Emitted Color	λd(nm)	Iv (mcd) Typ. (Per Segment)	V_{F (Volt)}	@I_{F (mA)}	Configuration	Surface Color
1	VD 562CG	Yellow	589	60	2.0	20	C.C	Gray
2	VD 552CG	Green	573	35	2.0	10	C.C.	Gray
3	VD 572CG	Red	624	60	2.0	20	C.C	Gray
