Victory's 1013 Dome 30° lens SMD LED

1013 Dome lens SMD LED production process:

Attach die to pcb with silver paste>curing the die with heat>Bond metallic wire between die and pcb>Package the LED with resin>Cutting the LEDs from pcb>Using machines to categorize the binning(brightness and color) into reels

1013 Dome lens SMD LED features:

1013Dome lens LED is high brightness with smaller view angle

View angle:30°

High luminous intensity

Blue & green use: InGaN

Yellow & Red use: AlGaInP

High performance model for True-green: VS 9328

3.2mm(length) x 2.4mm(width) x 2.6mm(height)

1013 Dome lens SMD LED applications:

Signal indicators

Backlight

Home appliance

Portable device

Industrial controls

1013 Dome Package

#	Part No	Emitted Color	λd(nm)	λp(nm)	Lens Color	Iv(mcd) Min.	Iv(mcd) Typ.	Angle (2θ ½)	V_{F (Volt)}	@I_{F (mA)}
1	VS 9228	Blue	470	468	Clear	715	1200	30	3.3	20
2	VS 9328	True-green	525	518	Clear	1800	3470	30	3.3	20
3	VS 9528	Green	573	575	Clear	280	355	30	2.0	20
4	VS 9628	Yellow	589	591	Clear	280	380	30	2.0	20
5	VS 9828	Yellow-orange	605	611	Clear	280	380	30	2.0	20
6	VS 9928	Orange	615	621	Clear	280	380	30	2.0	20
7	VS 9728	Red	624	632	Clear	280	380	30	2.0	20
