Victory's Bi-Color SMD LED Product Range


Production process:
Attach die to pcb with silver paste>curing the die with heat>Bond metallic wire between die and pcb>Package the LED with resin>Cutting the LEDs from pcb>Using machines to categorize the binning(brightness and color) into reels

Sizes:
●Top view 1210 Package(3.2x2.7x1.1mm) =120° view angle
●Top view 1209 Package(3.0x2.5x1.5mm) =  60° view angle
●Top view 0706 Package(1.9x1.6x0.8mm) =130° view angle
●Top view 0606 Package(1.6x1.5x0.6mm) =120° view angle
●Top view 0605 Package(1.6x1.3x0.4mm) =120° view angle
●Top view 0603 Package(1.6x0.8x0.5mm) =120° view angle

Applications:
Signal indicators
Backlight
Home appliance
Portable device
Industrial controls
# PDF Part No Emitted Color λd(nm) Lens Color Iv(mcd) Min. Iv(mcd) Typ. Angle (2θ ½) VF (Volt) @IF (mA)
1 VS Q62H8M Yellow
Blue 		589
470 		Clear 12
15 		20
30 		140 2.0
3.3 		5
2 VS Q63H8 Yellow
True-green 		589
525 		Clear 90
180 		180
300 		140 2.0
3.3 		20
3 VS Q82H8 Yellow-orange
Blue 		605
470 		Clear 57
35 		120
70 		140 2.0
3.5 		20
4 VS Q83H8 Yellow-orange
True-green 		605
525 		Clear 57
140 		120
200 		140 2.0
3.5 		20
5 VS QJH8 Red
Green 		573
624 		Clear 28
45 		45
90 		140 2.0
2.0 		20
6 VS QKH8 Green
Yellow 		573
589 		Clear 15
20 		30
40 		140 2.0
2.0 		20
7 VS QLH8 Red
Blue 		624
470 		Clear 45
23 		78
32 		140 2.0
2.0 		20

# PDF Part No Emitted Color λd(nm) Lens Color Iv(mcd) Min. Iv(mcd) Typ. Angle (2θ ½) VF (Volt) @IF (mA)
1 VS L7378 Red
True-green 		624
518 		Clear 280
450 		710
1120 		60 2.0
2.0 		20
2 VS L8578 Yellow-orange
Green 		605
573 		Clear 71
56 		95
85 		60 2.0
2.0 		20
3 VS LF78 Yellow
Blue 		589
470 		Clear 90
71 		155
115 		60 2.0
3.5 		20
4 VS LH78 Red
Yellow 		624
589 		Clear 22.4
22.4 		55
55 		60 2.0
2.0 		20
5 VS LJ78 Red
Green 		624
573 		Clear 35
18 		70
35 		60 2.0
2.0 		20
6 VS LK78 Yellow
Green 		589
573 		Clear 35
18 		70
35 		60 2.0
2.0 		20
7 VS LL78 Red
Blue 		624
470 		Clear 90
71 		145
115 		60 2.0
3.5 		20

# PDF Part No Emitted Color λd(nm) λp(nm) Lens Color Iv(mcd) Min. Iv(mcd) Typ. Angle (2θ ½) VF (Volt) @IF (mA)
1 VS R65F8 Yellow
Green 		589
573 		591 Clear 14 35.5 130 2.0 20
2 VS RJF8 Red
Green 		624
573 		632
575 		Clear 36
22 		60
40 		130 2.0
2.0 		20
3 VS RLF8 Red
Blue 		624
470 		632
468 		Clear 36
22 		60
40 		130 2.0
3.5 		20

# PDF Part No Emitted Color λd(nm) λp(nm) Lens Color Iv(mcd) Min. Iv(mcd) Typ. Angle (2θ ½) VF (Volt) @IF (mA)
1 VS TJD8 Red
Green 		624
573 		632
575 		Clear 35.5
22.4 		57
33 		120 2.0
2.0 		20
2 VS TLD8 Red
Blue 		624
470 		632
468 		Clear 14
14 		22
22 		120 2.0
3.5 		20
3 VS TMD8 Yellow-orange
Blue 		605
470 		611
468 		Clear 71
35.5 		117
60 		120 2.0
3.5 		20

# PDF Part No Emitted Color λd(nm) λp(nm) Lens Color Iv(mcd) Min. Iv(mcd) Typ. Angle (2θ ½) VF (Volt) @IF (mA)
1 VS 3JD8 Red
Green 		624
573 		632
575 		Clear 22.4
9 		37
15 		120 2.0
2.0 		20
2 VS 3KD8 Yellow
Green 		589
573 		591
575 		Clear 18
9 		27
15 		120 2.0
2.0 		20
3 VS 3LD8 Red
Blue 		624
470 		632
468 		Clear 71
45 		105
82 		120 2.0
3.5 		20
4 VS 3QD8 Red
True-green 		624
525 		632
518 		Clear 71
90 		115
135 		120 2.0
3.2 		20

# PDF Part No Emitted Color λd(nm) Lens Color Iv(mcd) Typ. Angle (2θ ½) VF (Volt) @IF (mA)
1 VS 285D8 Yellow-orange
Green 		605
573 		Clear 50
35 		120 2.0
2.0 		20
2 VS 2FD8 Yellow
Blue 		589
470 		Clear 60
40 		120 2.0
3.5 		20
3 VS 2JD8 Red
Green 		624
573 		Clear 80
35 		120 2.0
2.0 		20
4 VS 2LD8 Red
Blue 		624
470 		Clear 90
45 		120 2.0
3.3 		20
5 VS 2MD8 Yellow-orange
Blue 		605
470 		Clear 60
40 		120 2.0
3.5 		20

# PDF Part No Emitted Color λd(nm) λp(nm) Lens Color Iv(mcd) Typ. Angle (2θ ½) @IF (mA)
1 VS 72TH8M Red
Blue 		631
470 		639
468 		Clear 22.4
36 		130 5
2 VS 7JH8M Red
Green 		624
573 		632
575 		Clear 25
10 		130 5
3 VS 7QH8M Red
True-green 		631
525 		639
518 		Clear 25
75 		130 5

# PDF Part No Emitted Color λd(nm) λp(nm) Lens Color Iv(mcd) Typ. Angle (2θ ½) VF (Volt) @IF (mA) Configuration
1 VS 7QA8 Red
True-green 		624
525 		632
518 		Clear 120
235 		100 2.0
3.5 		20 C.A.
2 VS 7SA8 Yellow
True-green 		589
525 		591
518 		Clear 150
230 		100 2.0
3.2 		100 C.A.

# PDF Part No Emitted Color λd(nm) λp(nm) Lens Color Iv(mcd) Typ. Angle (2θ ½) VF (Volt) @IF (mA) Configuration
1 VS 7JC8 Red
Green 		624
573 		632
575 		Clear 54
30 		120 2.0
2.0 		20 C.A.
2 VS 7KC8 Yellow
Green 		589
573 		591
575 		Clear 50
30 		120 2.0
2.0 		20 C.A.
3 VS 7LC8 Red
Blue 		624
470 		632
468 		Clear 35
30 		120 2.0
3.5 		20 C.A.

# PDF Part No Emitted Color λd(nm) λp(nm) Lens Color Iv(mcd) Min. Iv(mcd) Typ. Angle (2θ ½) VF (Volt) @IF (mA)
1 VS 8JD8 Red
Green 		631
573 		639
575 		Clear 45
22.4 		80
0 		130 2.0
2.0 		20
2 VS 8KD8 Yellow
Green 		589
573 		591
575 		Clear 35.5
18 		85
60 		130 2.0
2.0 		20
3 VS 8MD8 Yellow-orange
Blue 		605
470 		611
468 		Clear 45
28 		90
50 		130 2.0
2.0 		20
