5050 SMD LED

Features:

●Package dimension: 5.0mm x 5.0mm
●View angle:120°
●Driving current 20mA
●High luminous intensity
●Compliant with RoHS & REACH regulations

Decorative lighting
Backlight
Indoor lighting
Signals lighting
Reading lights

#	Part No	Emitted Color	CIE-XY	λd(nm)	λp(nm)	Lens Color	Iv(mcd) Min.	Iv(mcd) Typ.	Angle (2θ ½)	V_{F (Volt)}	@I_{F (mA)}
1	VR K1A9.525	Warm White	X 0.38 Y 0.40	-	-	Yellow Diffused	4500	7100	120	3.0	20
2	VR KWA9.525	White	X 0.29 Y 0.30	-	-	Diffused	4500	7100	120	3.0	20
3	VR K2A85	Blue	-	470	468	Clear	1000	1250	120	3.2	20
4	VR K3A85	True-green	-	525	518	Clear	6000	6250	120	3.2	20
5	VR K6A85	Yellow	-	589	591	Clear	1500	1750	120	2.2	20
6	VR K7A85	Red	-	625	615	Clear	2300	2550	120	2.0	20
